What’s a Transition State?

Last updated: August 22nd, 2022 |

Here’s a question that comes up a lot: What’s a transition state?

A transition state is a very short-lived configuration of atoms at a local energy maximum in a reaction-energy diagram (aka reaction coordinate).

  • A transition state has partial bonds, an extremely short lifetime (measured in femtoseconds), and cannot be isolated.

Tip: Don’t confuse a transition state with an intermediate. An intermediate is a species at an energy minimum in a reaction coordinate, and is (in theory) isolable.  Carbocations and free-radicals are examples of intermediates.


Transition State = The Point Of Maximum Pain

In the Harry Potter series, Remus Lupin changed to his werewolf form when the moon was full. But he didn’t go from human to werewolf just by snapping his fingers:  the fangs and hair had to grow, the spine curled, the hands became more pawlike and the fingernails lengthened into claws. If you saw the movies, the business of transforming from human to werewolf didn’t look like a whole lot of fun! You can imagine that the extent to which Remus disliked transforming into a werewolf was proportional to the pain involved. That point of maximum pain – where Lupin is half-man, half-werewolf – is a lot like a transition state.

Like the most painful part of transforming from a human to a werewolf, a transition state is at a local energy maximum: it has partial bonds and cannot be isolated as an individual molecule.

Let’s try to demonstrate what that means.

The Transition State In The SN2 Reaction

Under certain conditions,  when you take a primary alkyl halide and add a good nucleophile, you end up forming a new carbon-nucleophile bond and breaking the carbon-halide bond. It’s a substitution reaction, since we’re exchanging one functional group for another. Here’s an example: the reaction between NaOH and CH3Br.

example-of-a-nucleophilic-substitution-reaction-sn2-naoh-plus-ch3br-giving-ch3oh-and-nabr

You might recognize this as an SN2 reaction (nucleophilic substitution, bimolecular).  Try to imagine how this is happening. You’re breaking the C-halide bond while at the same time forming a new carbon-nucleophile bond. Since you can’t have a stable carbon with 5 full bonds (it would have 10 electrons and thus violate the octet rule) here has to be some point where you have partial bonds.

[Imagine runners in a relay race. There is a brief moment in each race where one runner is passing the baton to the other, where neither has complete possession of the baton (electrons, in our analogy) but it is shared between the two. That’s the analogy here.]

Drawing out the reaction, it looks a little like this (using Nu as a substitute for OH(–) and M as a substitute for Na(+) to make it more general). That’s the transition state. Again, it is the point of highest energy (most unstable), since you have two partial bonds at their maximum (weakest) lengths. Furthermore, the geometry has gone far from the ideal (tetrahedral) to one with more steric interactions (trigonal bipyramidal)

drawing-of-transition-state-for-nucleophilic-substitution-reaction-between-ch3br-and-nucleophile

Since this is a pretty painful and unhappy state of affairs for both molecules involved, the lifetime of the transition state is extremely short – on the order of femtoseconds – and rapidly relaxes to the product.

We have a name for this point of “maximum pain”:  the difference between the energy of the starting material and the transition state (the point of “maximum pain”) is called the “Activation energy“.

So given a diagram for the progress of a reaction, you can figure out the activation energy by subtracting the energy of the transition state from the energy of the product.

reaction-energy-diagram-for-a-simple-substitution-reaction-sn2-showing-transition-state-for-a-reaction-coordinate

This graph shows the reaction of CH3Br (A) with a nucleophile (Nu) that goes through a transition state (B) to yield a product, CH3Nu (C) [in addition to Br(–), not shown]

  • The activation energy would be E of the TS (B) minus the E of the starting material (A).
  • Notice another thing for this reaction: the product (CH3Nu) is lower in energy than the starting material (CH3Br). We can figure out the overall energy for the process by subtracting the energy of the product from the energy of the starting material:Energy given off by the reaction = Energy of product (C) minus Energy of starting material (A).
  • You can even figure out the activation energy for the reverse reaction: that would be the energy of the transition state (B) minus the energy of the product (C); in this case the activation energy will be higher since the product C is more thermodynamically stable:
  • Activation energy for reverse reaction = energy of transition state (B) – energy of product (C).

Key things to remember here:

1) you can’t isolate a transition state – it has partial bonds

2) you can calculate the energies of a reaction (qualitatively) by examining a reaction energy diagram.

Comments

Comment section

16 thoughts on “What’s a Transition State?

  1. If a transition state is stabilised, we often say that the reaction is favoured in forward direction, but my question is, if the TS is stable, why would the reaction proceed, why wouldn’t it stop there and retard the rate of forward reaction?

    1. -When you have two populations on either side of a steep range of mountains, the fastest route between them is not over the mountain peaks, but through the lowest pass.
      -The lower the altitude of the mountain pass, the easier it will be to go through the mountain range.
      -But people don’t generally settle on the pass. They live in the valleys.

      The TS is not a stable molecule. It has partial bonds and partial charges. It has an extremely short lifetime. But if you lower the energy of the transition state, like lowering the altitude of a mountain pass, you will increase the rate at which the reaction proceeds.

  2. If the TS of one rxn is higher in terms of energy than the other TS then is the 1st rxn slower than the 2nd? (generally speaking)

    1. What’s faster to climb, a 10,000 foot mountain or a 15,000 foot mountain?

      Depends on where you start! If your base camp for mountain #1 is at sea level, and your base camp for mountain #2 is at 14,000 feet, then climbing mountain #2 is easier! (assuming they are of equal difficulty).

      In chemistry terms, the difference between the height (energy) of the basecamp (reactants) and the summit (transition state) is referred to as the activation energy. The rate of a reaction is related to the activation energy through the Arrhenius equation k = A e (-Ea/RT)

  3. So would the “leaving group” stabilize the transition state? Or does that not happen, because the leaving group is already attached the molecule in the first place and the nucleophile is the one attacking, forming and stabilizing the transition state?

    1. Computational chemistry techniques, in particular density-functional theory (DFT) with a software package like Gaussian is very powerful. For many examples see the beautiful work of Prof. Kendall Houk at UCLA: https://www.chem.ucla.edu/houk/ . To take one example of many, Paul H.-Y. Cheong, Robert S. Paton, Sarah M. Bronner, G-Yoon J. Im, Neil K. Garg, and K. N. Houk: “Indolyne and Aryne Distortions and Nucleophilic Regioselectivities,” J. Am. Chem. Soc., 132, 1267-1269 (2010)

    1. Transition state is at the TOP of the peak.

      “Activated complex” is meant to be a less specific term. It refers to the structure of the assembly of atoms around the energy of the transition state, incorporating not only the transition state but the structure at intermediate energies. It allows us to discuss the structure of the assembly of atoms that are close in energy to the transition state but not quite at the point of highest energy.
