Alkyne Reactions

By James Ashenhurst

Alkyne Reaction Patterns – Hydrohalogenation – Carbocation Pathway

Last updated: September 21st, 2020 |

Alkyne Hydrohalogenation – Addition of HX To Alkynes – HCl, HBr, and HI

In the previous three posts on alkynes we’ve introduced some new reactions that are specific to alkynes (versus alkenes):

With all the focus on the ways in which alkyne chemistry can differ from alkene chemistry, it’s helpful to be reminded of all the ways in which they are similar.

In this post we’ll go back to a key reaction mechanism pattern we observed with alkenes: the so-called, “carbocation pathway” – and explore how many of the reactions of alkenes we’re familiar with can also be used with alkynes.

Table of Contents

  1. Addition of Hydrogen Halides (HCl, HBr, HI)  To Alkynes – Once
  2. Addition Of A Second Equivalent Of HX To A Vinyl Halide Gives A Geminal Dihalide
  3. Addition of Hydrogen Halides To Alkynes – The Mechanism
  4. Comparing Alkenes and Alkynes In The “Carbocation Pathway”.
  5. Summary: Addition of Hydrogen Halides To Alkynes
  6. Notes (+ Termolecular Mechanism!)
  7. (Advanced) References and Further Reading

1. Addition of Hydrogen Halides To Alkynes (Once) – Hydrohalogenation

The three major examples in this category are the reaction of hydrohalic acids (H-Cl, H-Br, and H-I) with alkynes. If you recall, when added to alkenes, these reagents were:

  1. attacked by the π bond of the alkene to give a carbocation (on the most substituted carbon, giving “Markovnikov” regioselectivity) followed by
  2. attack of halide ion on the carbocation.

Since alkynes merely differ from alkenes in the addition of a second π bond, we would expect that these reactions would also work for alkynes as well – and they do!

addition of hcl to alkyne on equiv gi es alkenyl chlkoride vinyl chloride same for hbr hi two equivs gives geminal dichloride markovnikov selectivity

If we treat an alkyne with a single equivalent of H–Cl [note – we’ll just use H-Cl in all of these examples, but HBr and HI work in exactly the same way] we end up forming an alkenyl chloride. Note that the chlorine atom ends up attached to the most substituted carbon of the alkene [“Markovnikov” regioselectivity].

Note that the product here still has a π bond.

2. Addition Of A Second Equivalent Of HX To An Alkyne

You might be wondering if it’s possible to for this π bond to react with a second equivalent of H-Cl. The answer is yes. [Note – it is possible to just “stop” the reaction at this stage if we use just one equivalent, because the product (alkenyl chloride) is less reactive towards HCl than the starting alkyne].

Indeed, if we add a second equivalent of H-Cl, it adds to either side of the C-C π bond, giving us the product where two chlorine atoms are on the same carbon. By the way, we call this a “geminal” dichloride (think Latin – “gemini” = twins).

We can also get this product if we simply add two equivalents of H-Cl to the starting alkyne.

3. Addition of Hydrogen Halides To Alkynes – The Mechanism For Hydrohalogenation

So how might this reaction work? In a very similar fashion to how H-Cl adds to alkenes.

mechanism for formation of alkenyl chloride passing through vinyl carbocation markovnikov addition of chloride to carbocation 2n equiv gives geminal

The first step is protonation of the alkyne with H-Cl in such a manner as to give the most stable carbocation intermediate. Since carbocations are stabilized to a greater extent by electron releasing alkyl substituents than by hydrogen, the new carbocation will form at the end of the alkyne bearing the carbon substituent. In the next step, the carbocation is attacked by the chloride ion to give the alkenyl chloride.

What about the second equivalent of H-Cl ? Given the fact that the geminal dichloride is the product here, the most reasonable mechanism for its formation is merely a repeat of the steps from the first reaction (as shown). However it’s worth pointing out one interesting feature. Note that the carbocation in this case bears a chloride ion. Since carbocations are electron poor, and chlorine is quite an electronegative element, it’s interesting to point out that the electron releasing ability of the alkyl group [and the ability of chlorine to donate a lone pair to the carbocation] “win out” here over the electron-withdrawing character of chloride ion.

As mentioned above, the reactions of alkynes with HBr and HI (as well as HF, just in case you’re curious) follow the exact same pathway.

[Note: there is considerable evidence to suggest that this reaction in fact proceeds not through a carbocation intermediate, but through a “termolecular” reaction incorporating two equivalents of H-X and the alkyne. This is covered inconsistently in courses and textbooks. I strongly suggest you double check your textbook to verify how it is taught in your course].

4. Comparing Alkenes and Alkynes In The “Carbocation Pathway”

It’s probably worth tying back this post to the post on alkenes and the carbocation pathway, noting the similarities and differences between the chemistry of alkenes and alkynes. Hopefully this table will prove useful:

comparing carbocation parthway alkyne versus alkene hcl hbr hi addition to alkyne can happen twice giving gemincal halides

5. Summary: Addition of Hydrogen Halides To Alkynes (Hydrohalogenation)

As with alkenes, reactions that follow this pathway proceed through a carbocation intermediate and provide the “Markovnikov” products as major.

The key difference in this pathway is that hydration of alkenes gives alcohols, whereas hydration of alkynes gives carbonyl derivatives (i.e. ketones/aldehydes) after keto-enol tautomerism of the intermediate enol.

In the next post, we’ll explore the “3-membered ring” pathway with alkynes.

Next Post: Alkynes – The 3-Membered Ring Pathway


Notes

Footnote: The “termolecular” pathway for hydrohalogenation of alkynes

The intermediacy of vinyl carbocations in addition to alkynes seems to belong in the bucket of “mechanisms that are oversimplified for an introductory audience”, with the hope that textbooks will reach consensus in the future.

Prof. Hilton Weiss of Bard College writes:

I’ve done a lot of work on this and, of course, I believe my own results. My initial paper denying the vinyl cation intermediate (before doing any research) was in JChemEd 1993, p 873… You might look at Maitland Jones’s textbook or Carey and Sundberg. Actually my current belief is that the vinyl cation is EXTREMELY RARE in additions to alkynes. In Stang’s paper on the rearrangement of the “t-butyl vinyl cation” by solvolysis of the corresponding triflate, he made the triflate ester by adding trifluoromethane sulfonic acid to t-butylacetylene. This addition occurred with NO rearrangement. If triflic acid (pKa =-10) won’t protonate an alkyne, nothing will. Conjugated alkynes (e.g. phenylacetylene) can form conjugated vinyl cations but only in strong acids. Aqueous acids are not even close. (H3O+ =-1.7, HBr = -9, HCl = -7). I would not be surprised if the strongest acids add via a short-lived ion pair but even that is rare. Most textbooks say that alkenes and alkynes react by the same mechanism: it’s easier for students as long as you don’t look too close. By the way, the termolecular mechanism does not involve a proton and a halide ion attacking the alkyne at the same time; too improbable. First there is a reversible pi complex between acid and alkyne followed by a halide attached anti periplanar at the more positive carbon.

Thank you to Prof Weiss for writing. A link to the J. Chem. Ed. article is here.


(Advanced) References and Further Reading

The addition of HX to alkynes is believed to go through a vinyl cation after initial protonation of the alkyne.

  1. Polar additions to olefins and acetylenes. V. Bimolecular and termolecular mechanisms in the hydrochlorination of acetylenes
    Robert C. Fahey and Do-Jae Lee
    Journal of the American Chemical Society 1968, 90 (8), 2124-2131
    DOI:
    1021/ja01010a034
    Hydrogen chloride adds to aryl acetylenes in acetic acid to give mixtures of a-chlorostyrenes and the corresponding vinyl acetate.
  2. Reaction of acetylenes with hydrogen chloride in acetic acid. Effect of structure upon AdR2 and Ad3 reaction rates
    Robert C. Fahey, Michael T. Payne, and Do-Jae Lee
    The Journal of Organic Chemistry 1974, 39 (8), 1124-1130
    DOI:
    1021/jo00922a024
    The preference for a mechanism depends on the individual structure of the alkyne and the overall reaction conditions.
  3. Solvolysis of vinyl triflates. Effect of alkyl substituents, solvents, and added nucleophiles
    Richard H. Summerville, Carol A. Senkler, and Paul v. R. Schleyer
    Journal of the American Chemical Society 1974, 96 (4), 1100-1110
    DOI:
    1021/ja00811a026
  4. Stereochemistry of vinyl cations and vinylic substitutions
    H. Summerville and Paul v. R. Schleyer
    Journal of the American Chemical Society 1974, 96 (4), 1110-1120
    DOI:
    10.1021/ja00811a027
    Alkynes react when heated with trifluoroacetic acid to give addition products. Mixtures of syn and anti addition products are obtained, and similar reactions occur with trifluoromethanesulfonic (triflic) acid. These reactions presumably also proceed through a vinyl cation intermediate.
  5. Theoretical investigations on carbocations. Structure and stability of C3H5+,C4H9+(2-butyl cation), C5H5+,C6H7+(protonated benzene), and C7H11+(2-norbornyl cation)
    Hans Joachim Koehler and Hans Lischka
    Journal of the American Chemical Society 1979, 101 (13), 3479-3486
    DOI:
    1021/ja00507a009
    One mechanism that has been proposed for this reaction is initial protonation of the alkyne via a bridged intermediate. This paper shows that this hydrogen-bridge structure is not energetically feasible. Various MO calculations place the bridged ion 30-45 kcal/mol above the vinyl cation in energy.
  6. Kinetics of the acid-catalyzed hydration of allene and propyne
    Paul Cramer and Thomas T. Tidwell
    The Journal of Organic Chemistry 1981, 46 (13), 2683-2686
    DOI:
    1021/jo00326a016
    Solvent isotope effects are indicative of a rate-determining protonation.
  7. Substituent effects on the acid hydration of acetylenes
    Annette D. Allen, Yvonne Chiang, A. J. Kresge, and Thomas T. Tidwell
    The Journal of Organic Chemistry 1982, 47 (5), 775-779
    DOI:
    1021/jo00344a006
    Alkyne reactivity increases with addition of electron-donating substituents. The reactivity of alkynes is somewhat more sensitive to substituent effects than is the case for alkenes.
  8. 2-Butyne and hydrogen chloride cocrystallized: solid-state geometry of Cl-H••p hydrogen bonding to the carbon-carbon triple bond
    Dietrich Mootz and Axel Deeg
    Journal of the American Chemical Society 1992, 114 (14), 5887-5888
    DOI:
    10.1021/ja00040a077
    The short length of this JACS communication belies the difficulty of this experimental work! This paper describes an X-ray structure of the addition complex between HCl and an alkyne, with the HCl perpendicular to the C-C p bond.
  9. The electrophilic addition to alkynes
    Hilton M. Weiss
    Journal of Chemical Education 1993, 70 (11), 873
    DOI:
    1021/ed070p873
    This paper argues that vinyl cations are too unstable and therefore cannot be intermediates in electrophilic additions to alkynes. This is not entirely correct, as vinyl cations have been observed in superacid media under the right conditions.
  10. Bromide assisted addition of hydrogen bromide to alkynes and allenes
    Hilton M. Weiss and Kim M. Touchette
    J. Chem. Soc. Perkin Trans 2 1998:1523
    DOI:
    10.1039/A703569A
    The reaction of 4-octyne with TFA in CH2Cl2 containing 0.1-1.0 M bromide ion proceeds mainly via anti addition. The presence of bromide ion greatly accelerates the reaction as compared to reaction with TFA alone, indicating the involvement of Br in the rate-determining step.
  1. Electron transmission study of the splitting of the p* molecular orbitals of angle-strained cyclic acetylenes: implications for the electrophilicity of alkynes
    Lily Ng, Kenneth D. Jordan, Adolf Krebs, and Wolfgang Rueger
    Journal of the American Chemical Society 1982, 104 (26), 7414-7416
    DOI:
    1021/ja00390a005
    Another possible explanation for the lower reactivity of alkynes relative to alkenes has to do with the availability of the unfilled orbital in the alkyne. It has been shown that a p* orbital of bent alkynes (e.g. cyclooctyne) has a lower energy than the p* orbital of alkenes, and it has been suggested that linear alkynes can achieve a bent structure in their transition states when reacting with an electrophile.
